Electrical Steel CRCA

Electrical Steel CRCA Coils are precision-engineered cold rolled close annealed steels developed specifically for superior magnetic performance. Available in specialised silicon and non-silicon grades, these coils are optimized to deliver excellent permeability, reduced hysteresis, and minimal eddy current losses.
Manufactured under strict quality controls, Electrical Steel CRCA ensures consistent thickness, smooth surface finish, and uniform magnetic properties—making it ideal for high-efficiency electrical applications..

Thickness : 0.20mm & above
Width : 6mm - 750mm

Electrical Steel CRCA Technical Specifications

Technical Specification	Details & Standards
Thickness	0.20mm & above
Width Range	6 mm – 1000 mm
Length (For Sheets)	up to 7000 mm
Temper	1/8 Hard , 1/4 Hard, 1/2 Hard, Full Hard
Surface Finish	Dull/Bright/Matt/Mirror
Grade	D/DD/EDD/Super EDD/IF
Edge	Mill Edge/ Slit Edge
Thickness Tolerance	+/- 0.02 mm
Width Tolerance	As per Specification
Coil Weight	0.250 MT – 10 MT
Coil ID	400 to 500 mm
Coil OD	Up to 1300 mm
Length Tolerance	- 0 mm/+2 mm
Camber Tolerance	1.50 mm Max. per 1000 mm

Industry We Serve

Primary Applications

We continue to serve highly demanding engineering and manufacturing sectors, providing critical materials for bicycle industry, hardware and furniture goods, automotive and precision parts, agriculture and tractor components, bearing manufacturing, electrical radiators, transformer cores and motor laminations.
